Technical Specifications
| Parameter | Range |
|---|---|
| Size Range | DN50 - DN2000 (2" - 80") |
| Pressure Class | 150LB - 2500LB (PN10 - PN420) |
| Temperature Range | -196°C to +650°C |
| Body Materials | WCB, WCC, LCB, LCC, CF8, CF8M, CF3, CF3M, WC6, WC9, C5, C12 |
| Trim Materials | 13Cr, SS304, SS316, SS316L, Stellite, Monel |
| Seat Type | Metal seated, resilient seated (NBR/EPDM/PTFE) |
| End Connections | RF Flanged, RTJ, BW, SW, Threaded |
| Design Standards | API 600, API 6D, GB/T 12234, BS 1414, DIN 3352 |
| Testing Standards | API 598, API 6D, GB/T 13927, ISO 5208 |
Industry Applications
Our gate valves are widely used across multiple industries:
- Oil & Gas: Pipeline isolation, wellhead equipment, tank farm isolation
- Power Generation: Steam isolation, feedwater systems, cooling water
- Water Treatment: Distribution mains, pump isolation, reservoir outlets
- Chemical Processing: Reactor isolation, transfer lines, tank drainage
- Petrochemical: Refinery units, cracking plants, storage terminals
- Mining: Slurry transport, tailings disposal, process water
- Pulp & Paper: Stock lines, chemical recovery, wastewater
- Marine: Ballast systems, cargo handling, fire protection
Gate Valve FAQ
What projects is Gate Valve suitable for?
Gate Valve is built for reliable full-open/full-close pipeline isolation and commonly used in petrochemical, power, municipal water, steam and high-pressure main lines. If you are not sure about the model, send us the working condition first.
What happens if the wrong gate valve is selected?
The common risk is infrequent operation with high sealing and low pressure-drop requirements. Valve selection is not only about size and price; medium, pressure, temperature and standards must be reviewed together.
What information is needed to quote gate valve?
Please provide size, pressure class, material, connection, medium, temperature, quantity, operation method, standard and certificate/testing requirements.
Can gate valve be customized?
Yes. Non-standard size, special material, sealing structure, connection, actuator, inspection documents and packing requirements can be discussed by project.
How is gate valve tested before shipment?
According to standards and order requirements, shell pressure, seat sealing, appearance, dimensions and documents can be checked. ITP, NDT, material and calibration documents can also be supported.
Can project documents be provided for gate valve?
Yes. Drawings, quality plan, ITP, material certificates, inspection reports, pressure test records, NDT/calibration/certificates can be prepared according to order requirements.
What is the delivery time for gate valve?
Regular stocked models can be arranged faster. Non-standard, special material, high-pressure or batch orders depend on technical confirmation and production schedule.
Why do prices vary so much for the same gate valve?
Differences usually come from material, pressure class, sealing structure, standard, testing requirements, actuator and document package. Technical conditions should be aligned before quotation.
What is often ignored when buying gate valve?
The most ignored part is site condition. Is the medium corrosive? Does temperature fluctuate? Is operation frequent? Is third-party inspection required? All these affect selection.
What if I only know the working condition, not the model?
No problem. Send medium, pressure, temperature, size, connection standard and quantity. We can first check whether Gate Valve is suitable.
Request a Gate Valve Quote
Our engineering team can recommend the optimal gate valve for your application. Provide your specifications and we will respond within 24 hours.
Email: info@chlgvalve.com Call: +86-15601794339
